Rebar Calculator
Slabs, footings, walls, columns, and beams. Bar schedule with linear metres, weight, and lap allowances per bar size.
Standard: 40x diameter (e.g. 10 mm bar = 400 mm lap). Structural: 50x.
Standard UK stock lengths: 6 m or 12 m. Used to calculate number of full bars to order.
Structural Elements
Job Costing (optional)
UK Market PricesFills in the material cost fields with current UK market prices. You can review and edit each price before applying.
Results
Total Linear Metres
-
metres (inc. laps & waste)
Total Weight
-
kg
Total Bars
-
@ 12 m stock
Elements
-
scheduled
Element Breakdown
| Element | Type | Description | LM (net) | LM (inc. laps+waste) | Weight (kg) |
|---|
Bar Schedule - by Diameter
| Bar dia. | Weight/m | Net LM | With laps+waste | Weight (kg) | Stock bars (@ 12 m) |
|---|
🚫 Estimate waste & skip size for this project →
Doing this as a homeowner?
Who do you actually need to hire for this?
Not sure what some of these terms mean?
Browse all →
Frequently Asked Questions
How much rebar do I need for a concrete slab?
Divide slab length by bar spacing and add 1 to get bar count in one direction; multiply by slab width for linear metres. Repeat for the other direction and add the totals. For T12 at 200 mm centres, you need approximately 10 lm per m² of slab (5 lm each direction). Add 10% for laps and waste.
What diameter rebar should I use for a concrete slab?
T10 at 200 mm centres suits lightly loaded domestic floor slabs. T12 at 150-200 mm centres for more heavily loaded slabs or longer spans. Bar diameter and spacing must be confirmed by a structural engineer for any loadbearing application. BRC fabric mesh (A193 or A252) is a common alternative to individual bars.
What is the minimum concrete cover to rebar under UK Building Regulations?
Per Eurocode 2 (BS EN 1992-1-1): internal floor slabs (exposure XC1) minimum 25 mm cover. Foundations in contact with soil (exposure XC2) minimum 40 mm cover. Coastal/exposed environments require greater cover. Always add a 10 mm construction tolerance to the nominal cover specified.
What is the lap length for rebar?
Typically 40d to 50d (40-50 times the bar diameter). For T12: minimum lap 480-600 mm. For T10: minimum lap 400-500 mm. Values vary with concrete grade, bar position and exposure class - always refer to the structural design for project-specific lap lengths.
What is the difference between T bar (high yield) and R bar (mild steel) rebar?
T bars (deformed high yield, grade B500B) have a 500 MPa yield strength and a ribbed surface for better concrete bond - now the standard for UK structural concrete. R bars (mild steel, smooth, 250 MPa) are rarely specified for structural work but used for links in some applications. New structural designs should use T bar (B500B) unless otherwise specified.
What waste allowance should I use for rebar?
Add 10% waste for cutting, laps and on-site offcuts. Rebar is typically supplied in 6 m or 12 m lengths - calculate full lengths needed after applying waste. For complex shapes with many short bars, use 15%. Order a small surplus as cut-to-length steel can take time to re-order.
